| 型号 | 基本尺寸（mm) Size | |||
| D1 | L1 | 筒夹 | 扳手 | |
| BT30-HSE16-60L | 27.5 | 60 | SE16 | D275-BS |
| BT30-HSE16-75L | 75 | |||
| BT30-HSE16-90L | 90 | |||
| BT30-HSE16-150L | 150 | |||
| BT30-HSE20-60L | 35 | 60 | SE20 | D35-BS |
| BT30-HSE20-75L | 75 | |||
| BT30-HSE20-90L | 90 | |||
| BT30-HSE20-150L | 150 | |||
| BT30-HSE25-60L | 40 | 60 | SE25 | D40-BS |
| BT30-HSE25-75L | 75 | |||
| BT30-HSE25-90L | 90 | |||
| BT30-HSE32-70L | 50 | 70 | SE32 | D50-BS |
| BT30-HSE32-75L | 75 | |||
| BT30-HSE32-100L | 100 | |||
| 型号 | 基本尺寸（mm) Size | |||
| D1 | L1 | 筒夹 | 扳手 | |
| BT40-HSE16-100L | 22 | 100 | SE16 | D22-BS |
| BT40 -HSE16-150L | 150 | |||
| BT40 -HSE16-70L | 27.5 | 70 | D27.5-BS | |
| BT40 -HSE16-100L | 100 | |||
| BT40 -HSE16-125L | 125 | |||
| BT40 -HSE16-150L | 150 | |||
| BT40 -HSE16-200L | 200 | |||
| BT40 -HSE20-70L | 35 | 70 | SE20 | D35-BS |
| BT40 -HSE20-100L | 100 | |||
| BT40 -HSE20-150L | 150 | |||
| BT40 -HSE25-70L | 40 | 70 | SE25 | D40-BS |
| BT40 -HSE25-100L | 100 | |||
| BT40 -HSE25-150L | 150 | |||
| BT40 -HSE32-70L | 50 | 70 | SE32 | D50-BS |
| BT40 -HSE32-100L | 100 | |||
| BT40 -HSE32-150L | 150 | |||
| 型号 | 基本尺寸（mm) Size | |||
| D1 | L1 | 筒夹 | 扳手 | |
| BT50-HSE16-100L | 27.5 | 100 | SE16 | D27.5-BS |
| BT50-HSE16-150L | 150 | |||
| BT50-HSE16-200L | 200 | |||
| BT50-HSE20-100L | 35 | 100 | SE20 | D35-BS |
| BT50-HSE20-150L | 150 | |||
| BT50-HSE20-200L | 200 | |||
| BT50-HSE20-250L | 250 | |||
| BT50-HSE25-100L | 40 | 100 | SE25 | D40-BS |
| BT50-HSE25-150L | 150 | |||
| BT50-HSE25-200L | 200 | |||
| BT50-HSE25-250L | 250 | |||
| BT50-HSE32-100L | 50 | 100 | SE32 | D50-BS |
| BT50-HSE32-150L | 150 | |||
| BT50-HSE32-200L | 200 | |||
| BT50-HSE32-250L | 250 | |||
